Thorium-Protactinium fate across the tropical Atlantic Ocean: what reveals the water column-sediment coupling

Twenty seawater profiles and twenty core-top 231-protactinium (231Pa) and 230-thorium (230Th) analyses were realised by Ng and colleagues (2020, see reference below) along five depth transects across the northern tropical Atlantic open ocean.  Among them, eighteen seawater-sediment pairs from nearby sites were compared. A thorough examination of this coupling associated to published data of 231Pa and 230Th in the North Atlantic Ocean, allow the authors to i) confirm the dominance of the 231Pa-export signal in the deep Atlantic associated with the southward advection of North Atlantic Deep Water (NADW) but also ii) observe contrasting local increases of sedimentary 231Pa/230Th above the production ratio, with higher values at intermediate depths (0.5–1.5 km) and in the eastern and mid-Atlantic sites. These last observations reflect either an additional input of 231Pa to the intermediate depths, or enhanced 231Pa scavenging at the eastern and mid-Atlantic sites, and/or the influence of boundary scavenging near the eastern margin.

Figure (modified from Ng, et al. 2020): Tropical Atlantic seawater 231Pa/230Th data and recently-deposited seafloor sediment 231Pa/230Th data. The map on the left shows the locations of seawater (square symbols) and sediment (circle symbols) data, and the red lines mark the boundary of the East-West depth section plotted on the right. The colour map in the depth section represents interpolated seawater 231Pa/230Th data, while the sediment 231Pa/230Th data is plotted overlain the seawater data as coloured circles. Seawater 231Pa/230Th is typically higher than the sediment 231Pa/230Th of a given site, reflecting the greater solubility of the 231Pa isotope. Sediment 231Pa/230Th values lower than the production ratio (0.093) indicate a net export of 231Pa, while sediment values higher than 0.093 reflect a net input of 231Pa, relative to 230Th. Sediment data may appear to be ‘below’ or ‘floating above’ the seafloor drawn in dark grey, because they are superimposed on a representative section across the Atlantic, rather than the overlying bathymetry measured at the actual sites.


Ng, H. C., Robinson, L. F., Rowland, G. H., Chen, S. S., & McManus, J. F. (2020). Coupled analysis of seawater and sedimentary 231Pa/230Th in the tropical Atlantic. Marine Chemistry, 227, 103894. DOI:
